Yarn Winder PET Strap Extrusion Line 200MM Plastic Strap Making Machine 8MM - 32MM

Product Categories
Foshan Yicheng Automation Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Yarn Winder PET Strap Extrusion Line 200MM Plastic Strap Making Machine 8MM - 32MM

Price : 7000 - 14000USD 1 set

Place of Origin : china

Brand Name : United Win

MOQ : 1 set

Packaging Details : Wooden Case

Delivery Time : 30days

Model Number : PETQZD-70

place of origin : Guangdong, China

brand name : Yicheng

voltage : 220V

dimension(l*w*h) : 1600mm * 1350mm * 2260mm

warranty : 1 Year

Weight (KG) : 890

Product name : Automatic Strap Winder

Maximum winding diameter : 800MM

Rewind-up range : 8MM-32MM

Length of paper tube : ≤200MM

Input power : 220V

Maximum power : 2.0 KW

Maximum operating pressure of the system : 0.8MPa

Minimum operating pressure of the system : 0.6MPa

Machine color : Standard color (7035 Grey + Blue)

Contact Now

Yarn Winder PP Strap Automatic Winding with Length of Paper Tube ≤200MM and Rewind-up Range of 8MM-32MM from Chinese
Products Description:

The 70kg fully automatic PET strapping rewinding machine revolutionizes production efficiency with its dual-mode (weight/length) operation and 720mm maximum winding capacity, seamlessly adapting between core and coreless configurations through intelligent swing-arm tension control and automated inflatable shaft technology. This advanced system guarantees flawless roll formation with perfectly aligned edges and uniform surface patterns, eliminating overlaps or visual defects while enabling single-operator multi-unit management - significantly reducing labor requirements and operational costs in high-volume strapping production environments through its precision-engineered winding mechanisms and smart production adaptability. formation with perfectly aligned edges and uniform surface patterns, eliminating overlaps or visual defects while enabling single-operator multi-unit management - significantly reducing labor requirements and operational costs in high-volume strapping production environments through its precision-engineered winding mechanisms and smart production adaptability.

Main specifications and parameters
Appearance and dimensions 1650mm*1400mm*2200mm Maximum winding diameter 800MM
Machine weight About 890KG Rewind-up range 8MM-32MM
Input power 220V Length of paper tube ≤200MM
Maximum power 2.0KW Equipment model PETQZD-70
Maximum operating pressure of the system 0.8MPa Minimum operating pressure of the system 0.6MPa
Yarn Winder PET Strap Extrusion Line 200MM Plastic Strap Making Machine 8MM - 32MM Yarn Winder PET Strap Extrusion Line 200MM Plastic Strap Making Machine 8MM - 32MM Yarn Winder PET Strap Extrusion Line 200MM Plastic Strap Making Machine 8MM - 32MM
